사양→ |
고내온도(℃) |
휜피치(mm) |
전열면적(㎡) |
열량(kcal/h) |
휀&모터
휀경xPHxkwxPxEA |
풍량(CMM) |
제상히타(kwxEA) |
무게(kg) |
|
temperature difference |
|
모델↓ |
TD10℃ |
TD7℃ |
TD5℃ |
몸통 |
|
KUC-M015 |
H |
+14~+18 |
4.5 |
16.57 |
6198 |
3483 |
1776 |
￠400x0.1x6x1 |
28 |
0.35x4 |
46 |
|
M |
+4~+8 |
6.5 |
11.99 |
4640 |
2621 |
1349 |
|
KUC-M020 |
H |
+14~+18 |
6.5 |
23.19 |
8675 |
4875 |
2485 |
￠450x0.2x6x1 |
38 |
0.45x4 |
56 |
|
M |
+4~+8 |
6.5 |
16.79 |
6498 |
3671 |
1890 |
|
KUC-M025 |
H |
+14~+18 |
4.5 |
29.91 |
11189 |
6288 |
3206 |
￠450x0.2x6x1 |
48 |
0.35x8 |
65 |
|
M |
+4~+8 |
6.5 |
21.66 |
8382 |
4736 |
2438 |
|
KUC-M030 |
H |
+14~+18 |
4.5 |
34.46 |
12891 |
7245 |
3694 |
￠500x0.2x8x1 |
56 |
0.4x8 |
74 |
|
M |
+4~+8 |
6.5 |
24.96 |
9660 |
5457 |
2805 |
|
KUC-M040 |
H |
+14~+18 |
4.5 |
42.79 |
16007 |
8996 |
4587 |
￠500x0.2x8x1 |
68 |
0.5x8 |
84 |
|
M |
+4~+8 |
6.5 |
30.99 |
11993 |
6776 |
3488 |
|
KUC-M050 |
H |
+14~+18 |
4.5 |
59.64 |
22314 |
12539 |
6393 |
￠450x0.2x6x2 |
97 |
0.7x8 |
108 |
|
M |
+4~+8 |
6.5 |
43.19 |
16715 |
9443 |
4861 |
|
모델→ |
L |
W |
H |
앵커치수 |
배관구경(￠) |
|
A |
B |
IN |
OUT |
DRAIN |
|
KUC-M015 |
H |
690 |
862 |
303 |
720 |
922 |
12.7 |
19.05 |
25A |
|
M |
|
KUC-M020 |
H |
890 |
912 |
303 |
720 |
972 |
12.7 |
19.05 |
25A |
|
M |
|
KUC-M025 |
H |
980 |
912 |
345 |
810 |
972 |
12.7 |
19.05 |
25A |
|
M |
|
KUC-M030 |
H |
1100 |
962 |
345 |
930 |
1022 |
15.88 |
28.58 |
25A |
|
M |
|
KUC-M040 |
H |
1320 |
962 |
345 |
1150 |
1022 |
15.88 |
28.58 |
25A |
|
M |
|
KUC-M050 |
H |
1450 |
912 |
408 |
1280 |
972 |
15.88 |
28.58 |
25A |
|
M |
|
